Lowrance Point-1 GPS Antenna and Magnetic Compass
000-11047-002
New
POINT -1 PRECISION GPS/GLONASS RECEIVER
WITH MAGNETIC COMPASS HEADING SENSOR
The Lowrance Point-1 is the ideal position and heading device. The Point-1 provides extremely accurate and rapid boat position and speed updates. In addition – unlike other position-only antennas – the Point-1 provides heading for accurate boat direction at any speed and for radar/chart overlay.
Can Collect Pre Paid at Durban Trade Counter or Courier Ships to Your Door
More info
Point-1 Antenna
PRECISION GPS/GLONASS RECEIVER WITH ELECTRONIC COMPASS
The Lowrance Point-1 is the ideal position and heading device. The Point-1 provides extremely accurate and rapid boat position and speed updates. In addition – unlike other position-only antennas – the Point-1 provides heading for accurate boat direction at any speed and for radar/chart overlay.
The Point-1 easily connects to any HDS Gen2, HDS Gen2 Touch or Elite-7 display or any NMEA 2000® network. It is fully waterproof and can be pole or surface mounted on any boat.
NB: Requires NMEA 2000 Network
KEY FEATURES
- NMEA 2000® position and heading sensor
- Supports GPS and GLONASS, Galileo-capable with future software update
- Supports SBAS including WAAS/EGNOS/MSAS
- 10 Hz updates for smooth and accurate location
- Integrated electronic compass provides 10Hz heading for chart stabilization and radar overlay, plus accurate course over ground even at low speeds
- Compact, rugged design for all marine environments and fully waterproof
- Includes spat/pole mount
- Not recommended for use with MARPA or Autopilot
WHAT’S IN THE BOX
- Antenna/4' cable
- 15' NMEA Cable
- T connector
- Spat/pole mount
- Mounting hardware
- Gasket seal
- Install guide
SPECIFICATIONS
| Networking Connectors | |
| NMEA 2000 Certified | Yes |
| Connectors | NMEA 2000 Micro C |
| Power | |
| Power Supply (Supply Voltage) | 9v-18v |
| Technical/Environmental | |
| Diameter [mm] | 90 mm |
| Humidity | 40 degrees C, 93%RH, operating |
| Product Depth [mm] | 90 |
| Product Weight | 0.3 lbs (approximately) |
| GPS Navigation | |
| GPS Receiver Channels | 32 |
| Heading Accuracy | 3 degrees |
| Horizontal Accuracy | 5 m |
| Rate of Turn | 3 degrees |
| Receiver Type | L1, C/A code, 1.575 GHz Frequency/ L2 C/A code, 1.602 GHz Frequency |
| Satellite Reacquisition | 5 seconds |
| Information | |
| Picth/Roll Angle | @30 degrees 1 grade error |
| Other | |
| Other Features |
Start-up Time: 3 seconds Cold Start: 50 seconds |
